Description
- Turbo Drive: Electronically driven by a high-performance turbine, no more driven gas
- Precise ventilation:Minimum tidal volume down to 4 mL，more friendly to tiny animals.
- Smart preset: Once inputting animal weight, smart respiratory parameters can be called up.
- Guard “breathing” safety: Accurate and continuous monitoring of respiratory status, such as airway pressure – time chart, minute volume, EtCO2, and etc.
- Multiple alarms: Multiple alarms and clear handling prompts ensure the safety of mechanical ventilation
- PEEP function: Help veterinarians solve low SpO2 problems during surgery
- Auto system leak test：Graphical guidance for quick start
- Remote control of inspiratory hold: During a CT scan of the chest or abdomen, help the animal to hold the inspiration and complete the CT scan
Specification
| Item | Specification |
| Working principle | Turbo drive |
| Size | 291mm×336mm×462mm |
| Net weight | 8.5kg |
| Animal weight range | 0.4 kg-150 kg |
| Respiratory rate | 2~60bpm |
| I:E | 1：1.0-1：4.0 |
| Tidal volume | 4-1500 ml |
| Peak inspiratory pressure | 5-50 cmH2O |
| PEEP | 3~20 cmH2O, OFF |
| Trig pressure | PEEP OFF: -10~ -1cmH2O，OFF； PEEP ON: -10~-4cmH2O，OFF |
| Touch screen | 7inch，1024*600px |
| EtCO2 measuring range | Measuring range :0mmHg – 114 mmHg |
| EtCO2 sample flow rate | 75mL/min |
Order Information
| Product Name | Catalog Number |
| Veterinary Electric Turbo Ventilator | R420 |
