1. Suitable for mice to guinea pigs range from 10g to 1kg.
2. Convenient for the setting of animal ventilator data by inputting animal weight.
3. Built-in VCV and PIPCV working mode.
4. Real-time graphical display of tracheal pressure.
5. Touch Screen with a 75-degree visual surface design for easy operation.
6. Provide safe and effective intermittent positive pressure ventilation (IPPV), volume and pressure modes are available.
7. Sound, intelligent text, error code and other fault alarm alerts
Suggested Weight Range |
10g~1kg |
Species | Mouse/Rat~Guinea Pig |
Tidal Volume Range (TV) | 0.05ml~5ml, Resolution: 0.001ml |
Peak Inspiratory Pressure (PIP) | 1~50cmH2O, Resolution: 1 cmH2O Accuracy: ±0.7 cmH2O |
PEEP | 0~10 cmH2O, Resolution: 1 cmH2O |
Breath Rate (bpm) | 10~300 bpm |
I:E Ratio | 20~80% |
Sigh Breath | Frequency: Every 10~999 or Manual Volume: 0~20% of tidal volume (in volume mode) or PIP (in pressure volume) |
Display | 7’’ LCD touchscreen, resistive |
Remote Communication | RS-485 |
Power Supply | 100~240VAC, 50/60Hz |
Input Power | 24V DC, adaptor: 40W Max |
Safety Alarms | Over-/Under-pressure, occlusion, high PEEP |
Dimensions | 320*210*180mm |
Weight | 5.1kg |
Operating Temperature | 4℃~40℃ (40°F~104°F) |
Operating Humidity | 20~80%, non-condensing |
Storage Temperature & Humidity | -10℃~70℃ (14°F~158°F), 20%~80% RH, non-condensing |
Cat No. | Product Description |
R415 | Small Animal Ventilator |
R415-AP | Accessory package for Anesthesia and Ventilator |
