Description
SA101 Rodent Treadmill is widely used in the research of physical fitness, endurance, motor injury, motor nutraceuticals, motor physiology, pharmacology, metabolic and cardiovascular research etc. It consists of the main unit, incorporating the drive, the shocker, the control unit with 7 Inch touch screen, the running belt enclosed within a chamber constructed of acrylic and aluminum. The chamber contains a shock grid, which serves as an aversive stimulus to motivate exercise. Two sizes are available in our company, smaller size for mice and a larger size for rats.
Advantages
Our rodent treadmills designed with Individual lane and programming, which is helpful for easy cleaning and accurate detection.
A variety of motion modes can be achieved, uniform speed, uniform acceleration, uniform deceleration, acceleration and deceleration mixed mode, etc.
Speed ranges from 0-100 meter /minute, resolution 0.01m/min.
Adopts IR sensor for effective pulse electric shock, which ensure avoiding blind area in detection.
Two kinds of exhaustion mode are available in our rodent treadmill,time and frequency.
Features
Single or multiple lanes for rats and mice, with individual lane design
Variable speed mode setting, different speeds can be set in sections
Equips with precision sensor detection and individual lane programming
Effective electric shock, pulse electric shock circuit design to avoid blind area
Adjustable frequency of audio stimulation
Two kinds of exhaustion mode, time and frequency
Airpuff stimulation, non-invasive and gentle
Upgrade of the detection of air puff energy metabolism is available
Specification
🔹 Basic Specification
| Application | 5 Rats/5 Mice |
| Commands | 7″ capacitive IPS LCD touch screen |
| Power | 100–240 VAC, 50–60Hz |
| Sound Level | < 60 dB (A) |
🔹 Operation
| Mode | uniform speed, uniform acceleration, uniform deceleration, acceleration and deceleration mixed mode |
| Speed | 0.1–100 m/min adjustable, resolution 0.01 m/min |
| Acceleration | 0.1–100 m/min² |
| Start/Stop | From the touch screen |
| Detection | When touch the electric shock grid |
| Stimulation | Pulse electric, sound, light |
| Shock | 0.1mA–10mA adjustable, pulse electric shock |
| Sound | 1000–10KHz frequency adjustable |
| Light | 1–5000Hz frequency adjustable |
| Lane slope | -25° ~ 25° |
| 5 kinds of exhaustion mode | Distance, Time & Shock |
| Results | Distance, running time, number of shocks, shock time, current, exhaustion state, speed |
| Data export | By USB flash drive in csv or excel |
| Data save | >1000 |
🔹 Physical Size
| Mouse Treadmill | Rat Treadmill | |
| Lanes | 5 lanes | 5 lanes |
| Overall Size | 69.5×69.5×42.5 cm (27.3×27.3×16.7 inch) | 69.5×69.5×44 cm (27.3×27.3×17.3 inch) |
| Running Belt Size | 69.5×69.5×34.5 cm (31.3×27.3×13.5 inch) | 69.5×69.5×34.5 cm (31.3×27.3×13.5 inch) |
| Lane Size (L×W×H) | 61×8.5×15 cm | 61×11.5×16.5 cm |
| Independent Lane Control | Yes | Yes |
| Shock Grid Size | 12×6 cm | 12×12 cm |
| Speed: 1–100 meter/minute | ||
| Lane slope degree:-25° ~ 25° | ||
| Acceleration: Adjustable acceleration in 0.1 meter/minute increments | ||
| Adjustable current stimulus: 0.01 – 10 mA | ||
| Treadmill controller: 32×34×12 cm (length × width × height), weight: 7.5 kg | ||
| Structure: Clear, removable acrylic maze walls and an aluminum frame | ||
Order Information
| Item No. | Product Description |
| SA101BM | Treadmill for 5 Mice (Sound, Light, Electric Stimulation, Adjustable acceleration, different time section, separate lane, adjustable lane length) |
| SA101BR | Treadmill for 5 Rats (Sound, Light, Electric Stimulation, Adjustable acceleration, different time section, separate lane, adjustable lane length) |
| SA101B | Treadmill for 5 Rats and 5 Mice (Sound, Light, Electric Stimulation, Adjustable acceleration, different time section, separate lane, adjustable lane length) |
